We are Authorised Dealer, Supplier, Service Provider of Light Duty Slotting Machines, Slotting Machines, and our set up is situated in Pune, Maharashtra, India.
TECHNICAL DATA | VSL-6 | VSL-10 | VSL-12 |
Adjustable Stroke | 10 to 150mm | 10 to 250mm | 10 to 305mm |
Longitudinal Movement | 200mm | 230mm | 330mm |
Cross Movement | 110mm | 230mm | 150mm |
Speed Adjuctment | 3 Speed | 3 Speed | 3 Speed |
Ram Adjustment | 150mm | 250mm | 305 mm |
Electric Motor | 1 HP | 1.5HP | 2 HP |
Weight (Approx.) | 300 kg | 400 kg | 500kg. |
Standard Accessories: Boring Bar, Motor Pulley, Counter V-Belt
Extra Accessories: Rotory Table with 36.1 Ration Diameter 250 mm., Electric Motor, Switch, True Chuck, V-Belt. All the parts shown in the photograph are not included in Standard Accessories.
